Datasheet
Machine details
Technical details
- turning diameter over bed310 mm
- turning diameter over slide rest178 mm
- turning length910 mm
- turning dia. in gap420 mm
- spindle turning speed range70 - 2000 U/min
- spindle bore38 mm
- number of feeds18 Stk
- feed range0,052 - 1,392 mm/U
- metrical thread cutting0,4 - 7 mm
- voltage230 / 50 V Hz
- total power requirement1,1 kW
- weight of the machine ca.0,45 t
- dimensions of the machine ca.1,6 x 0,8 x 1,4 m
kein Zusatz angegeben
kein Zubehör angegeben
Description
incl. 3 and 4 jaw chuck Ø 160 mm
fixed and followed steadies
reducing bush MK4 - MK3
quadruple steel holder
change gear set
coolant device
SINO 2-axis digital display
variable speeds by means of inverter, clockwise + anticlockwise rotation
Documents & Videos
No video for this machine at the moment
