Datasheet
Machine details
Technical details
- Working width1400 mm
- Roller width1600 mm
- pressure40 t
- Pressure line250 N / mm
- Number of rollers2 Stück
- Upper roll320 dia
- Roller coveringStahl, verchromt
- Heating - upper rollThermoöl
- Swimming roll - dia355 mm
- Roller coveringFlexroll-Manchon
- Clouth speed30 m/min
- Weight10 to
- dimensions of the machine ca.3,0 x 4,0 x 2,5 m
kein Zusatz angegeben
kein Zubehör angegeben
Description
Inlet side with bearing cap for small skeins,
At outlet with Sochor arm and hydr. center winder,
with thermic oil heating, Make: TOOL-TEMP, Switzerland, Type TT-380.
