Datasheet
Machine details
Technical details
- Working widths6000 mm
- Roller width6200 mm
- Number of rollers2 Stück
- Supporting roller - dia490 mm
- Roller covering - soft rubber75 Grad shore
- Swimming roll - dia340 mm
- Roller covering - soft rubber75 Grad shore
- Pressure line25 N / mm
- Pressure total16 to
- Cloth guiding systemBreithalter,1 Leitwalze
- Liquor trough with guide rollheb + senkbar
- Drive sidenach Auftrag
- Operting sidenach Auftrag
- Compensatorpneum. Entlastung
- Drive shaftDurchmesser 70 mm
- required power30 m/min =14 kW
- Hydraulic unit for combined pressureaus Edelstahl
kein Zusatz angegeben
kein Zubehör angegeben
