Datasheet
Machine details
Technical details
- Bohrleistung in Stahl (-Ø50 mm
- throat1500 mm
- workpiece height max.1380 mm
- Bohrleistung in Guß (-Ø60 mm
- Abstand Spindelmitte bis Säule320 - 1250 mm
- swival range +/-180 °
- base plate surface area2640 x 1000 mm
- max. torque on the spindle310 Nm
- Bohrspindel-Ø/ Aufnahme75 mm /MK 5
- bore spindle stroke310 mm
- spindle turning speed range28 - 2500 U/min
- feed:0,05 - 2 mm/U
- power capacity4 kW
- weight of the machine ca.4,3 t
kein Zusatz angegeben
kein Zubehör angegeben
Description
cube table 500 x 500 x 500 mm
Documents & Videos
No video for this machine at the moment
