• pressure200 t
• stroke400 mm
• table surface area1300 x 600 mm
• feed under pressure1,8 mm/sec
• feed down7,2 mm/sec
• feed up9,2 mm/sec
• column daylight1300 mm
• daylight between the side columns450 mm
• total power requirement7,5 kW
• weight of the machine ca.2,3 t
• dimensions of the machine ca.2,3 x 0,9 x 2,5 m

• new press
• moveable pressure cylinder,
• additional manual pump, 2 options of speed
• 2 support prisms
• CE marking
