• Dreh-Øüber Bett400 mm
• Dreh-Øüber Support220 mm
• turning length1000 mm
• spindle turning speed range12,5 - 2000 U/min
• spindle taperBajonett 55022
• spindle bore47 mm
• feeds - longitudinal0,07 - 4,16 mm/U
• feeds - cross0.035 - 2,08 mm/U
• thread - mm pitch0,87 - 192 mm
• thread - inch2 - 24 Gang/ inch.
• rapid travel - longitudinal/face3,4 / 1,7 m/min
• spindle drive11 kW
• power capacity13 kW
• weight of the machine ca.2,8 t
• dimensions of the machine ca.2,8 x 1,2 x 1,5 m

• 3-jaw chuck Ø 250 mm, 4-jaw chuck 200 mm,
• 2-axis- digital display, ANILAM WIZARD LATHE - refinished in 1992,
